SG -30A
Product model: SG-20A/30A/50A/75A
Operating environment: 0 ℃~55 ℃
Humidity: less than 90% (no condensation)
Vibration: less than 0.5g (4.9m/s ²)
Work system: continuous operation
产品特点
-
-
控制精度高
The SG series servo drive can conveniently control the position, speed, acceleration, and output torque of the servo motor
-
-
-
矩频特性好
The successful development of SG series servo drives has brought infinite vitality to the field of transmission control.
-
-
-
具有过载能力强
The SG series servo drive core adopts 32-bit CPU to achieve full digital control of the motor, making it the most competitive electrical transmission product in the mechanical manufacturing industry.
-
-
-
防水等级高
The SG series universal servo drive is developed based on the requirements of position, speed, and torque control in the field of automation. It is the preferred product for motion control in CNC machine tools, textiles, plastic machines, papermaking, and various automated assembly lines.
-
产品详情
型号 | SG-15A | SG-20A | SG-30A | |
输出功率(kw) | 0.2-1.0 | 0.4-1.5 | 0.8-2.4 | |
电机额定转矩(N.m) | 0.6-4.0 | 2.4-6.0 | 4.0-15.0 | |
三相AC220V -15%~+10% 50/60Hz | ||||
控制方式 | SG系列位置控制、速度控制 | |||
控制特性 | 速度频率响应 | ≥250 Hz | ||
速度波动率 | +-0.03(负载0~100%), +-0.02(电源-15% ~+10%){数值对应于额定速度}, | |||
调速比 | 1:5000 | |||
脉冲频率 | ≤500k Hz | |||
控制输入 | 1.伺服准备好输出 2.报警清楚 3.CCW驱动禁制 4.CW驱动禁制 5.偏差计数器清零/速度选择1/零速钳位 6.指令脉冲禁止/速度选择2 | |||
控制输出 | 1.伺服准备好输出 2.伺服报警输出 3.定位完成输出/速度到达输出 4.机械制动输出 | |||
位置控制 | 输入方式 1.脉冲+符号 2.CCW脉冲/CW脉冲 3.两相A/B正交脉冲 | |||
电子齿轮 1~32767/ 1~32767 | ||||
反馈脉冲:2500 ppr | ||||
监视功能 | 转速、当前位置、指令脉冲积累、位置偏差、电机转矩、电机电流、直线速度、转子绝对位置、指令脉冲频率、运行状态、输入输出端子信号等 | |||
加减速功能 | 参数设置 1~10000ms/1000r/min | |||
保护功能 | 超速、主电源过压欠压、过流、过载、制动异常、编码器异常等、控制电源异常、位置超差等 | |||
